Dimensions(mm)
| Model | K2700 | |||||||
|---|---|---|---|---|---|---|---|---|
| Rear deck | Long/Low | Extra Long/Low | Long/High(4WD) | |||||
| Cabin type | Standard | Double | Standard | Super | Double | Standard | Double | |
| Seat capacity | 3 | 6 | 3 | 3 | 6 | 3 | 6 | |
| Overall length | 4,825 | 4,810 | 5,125 | 5,115 | 5,125 | 4,825 | 4,810 | |
| Overall width | 1,740 | 1,740 | 1,740 | 1,740 | 1,740 | 1,740 | 1,740 | |
| Overall height | 1,975 | 1,975 | 1,970 | 1,970 | 1,970 | 1,970 | 2,090 | |
| Wheelbase | 2,415 | 2,415 | 2,615 | 2,615 | 2,615 | 2,415 | 2,415 | |
| Front overhang | 1,205 | 1,205 | 1,205 | 1,205 | 1,205 | 1,205 | 1,205 | |
| Rear overhang | 1,205 | 1,190 | 1,305 | 1,295 | 1,305 | 1,205 | 1,190 | |
| front wheeltread | 1,490 | 1,490 | 1,490 | 1,490 | 1,490 | 1,490 | 1,505 | |
| Rear wheeltread | 1,340 | 1,340 | 1,340 | 1,340 | 1,340 | 1,460 | 1,460 | |
| Interior leg room(1st) | 985 | 985 | 985 | 985 | 985 | 985 | 985 | |
| Interior leg room(2nd) | - | 705 | - | - | 705 | - | 705 | |
| Interior head room(1st) | 1,026 | 1,026 | 1,026 | 1,026 | 1,026 | 1,026 | 1,026 | |
| Interior head room(2nd) | - | 995 | - | - | 995 | - | 995 | |
| Interior shoulder room(1st) | 1,473 | 1,473 | 1,473 | 1,473 | 1,473 | 1,473 | 1,473 | |
| Interior shoulder room(2nd) | - | 1,470 | - | - | 1,470 | - | 1,470 | |
| Rear deck length | 2,810 | 1,870 | 3,110 | 2,860 | 2,185 | 2,810 | 1,870 | |
| rear deck width | 1,630 | 1,630 | 1,630 | 1,630 | 1,630 | 1,630 | 1,630 | |
| rear deck height | 355 | 355 | 355 | 355 | 355 | 355 | 335 | |
| Rear deck deck height | 754 | 754 | 733 | 733 | 733 | 844 | 844 | |
| Rear deck deck Weight | 201 | 155 | 216 | 201 | 174 | 229 | 171 | |
| Ground clearance | 145 | 145 | 145 | 145 | 145 | 203 | 203 | |
| Fuel tank capacity(litres) | 60 | 60 | 60 | 60 | 60 | 60 | 60 | |
